The System 5™ features:
◾ A multi-pocketed, heavy duty 600D nylon attaché style case that keeps each component securely in place, yet instantly accessible
◾ Dual zipper closure permits rapid access, and protects against the elements
◾ Measures a compact 10 x 9 x 4 when closed, weighs just 2 1/2 lbs.
◾ Compact enough to fit in most emergency bags or trauma boxes
◾ Reinforced carry handle allows for wall mounting in the open position
◾ Includes Child, Small Adult, Adult, Large Adult, and Thigh Adcuff™ nylon cuffs featuring the Size Guide™ marking system
◾ Quick release luer slip connector to permit rapid selection of the appropriate cuff
◾ Revolutionary Diagnostix™ #804 palm style manometer with precision Japanese engineered movement rated to 50,000 cycles
◾ Ambidextrous trigger release air valve
◾ Assembled, inspected, and packaged in the U.S.A. from foreign components
◾ Meets or exceeds ANSI/AAMI/ISO 81060-1
Specifications:
Sphyg Type: Multicuff
Gauge: 804
Gauge Warranty: Lifetime
Sphyg Accuracy: /-3mmHg @ 50ºF(10ºC) - 104ºF(40ºC)
Sphyg Accuracy: at extended temperature range /-3mmHg or 2% whichever is greater @ <50ºF(10ºC) and >104ºF(40ºC)
Storage Temp: -4ºF (-20ºC) - 131ºF(55ºC)
Valve Type: Integral
Number of tubes: 1 Tube
Cuff type: ADCUFF
Cuff size: Multiple
Cuff Range: 13-66cm
Inflation Warranty: 3 Year
Zipper case: 883B
The ADC Difference:
◾ Latex-Free: Contains NO latex.
◾ Size Guide Marking System: Comprehensive cuff markings that promote proper cuff positioning and prevent mis-cuffing.
◾ Luminescent Dial: Graduation marks, numbers & indicator needle are luminescent for easier reading in low light.
◾ Extended Scaleplate Graduation marks that extend beyond the indicator needle to eliminate parallax error.
◾ 3 Year Warranty: Warranty extends to the original retail purchaser, commences with date of delivery and extends for a period of three years.
◾ Lifetime Calibration Warranty: Manometer will be recalibrated free of charge for LIFE.
◾ Domestic Content: Inspected, Assembled & Packaged in the USA.
